JSW NEOSTEEL EDS BARS

JSW Neosteel EDS TMT bars are Extra Ductile and Super strong. JSW Neosteel EDS bars are Fe 550D grade, hence are stronger than ordinary TMT bars. Special chemistry and post rolling treatment is used to make these bars more ductile, and thus, more flexible than regular TMT bars.

A more ductile, and flexible TMT bar is vital for increased protection of the structure from earthquakes. When a TMT Bar is flexible, it can withstand the shocks of earthquakes much better than an ordinary stiff TMT bar. Higher flexibility allows the TMT bar to bend without breaking at loads, higher than yield strength, but below the tensile strength of the TMT bars. Extra ductility of the JSW Neosteel EDS bars allows them to bend much more without breaking. Thus, offering higher protection to your homes from the shocks of an earthquake.

JSW Neosteel EDS facilitates the construction of homes, apartments, buildings and structures designed for earthquake loads applicable as per the IS codes.

Product Properties

Mechanical Properties IS 1786:2008 for Fe 550D JSW Neosteel Fe 550D IS 13920:2016* JSW Neosteel EDS 550D
YS (Mpa) (Min) 550 570 550 570
UTS (Mpa) (Min) 600 630 600 670
UTS/YS (Min) 1.08 1.12 1.15 1.15-1.18%
%EL (Min) 14.5 16 14.5 16%-18%
Total %EL at Max force 5 7 5 7
Dia (mm) 8-25mm 8-25mm
Chemical Properties IS 1786:2008 for Fe 550D JSW Neosteel Fe 550D IS 13920:2016* JSW Neosteel EDS 550D
% C (Max) 0.25 0.24 0.25 0.23
% P (Max) 0.04 0.04 0.25 0.03
% S (Max) 0.04 0.04 1.15 0.03
CE (Max) 0.075 0.07 14.5 0.5
% S+P (Max) 0.012 0.012 0.012 0.06
Nitrogen (ppm) 0.61 0.5 0.61 1.00

*Ductile Design & Detailing of Reinforced Concrete Structures subjected to Seismic Forces-Code of Practice

6X secure advantages

  • High Strength-550D
